The Fanvil GA10 is a compact SIP ATA gateway with an easy-to-use FXS port that enables users to take advantage of VoIP on analog phones. It supports G.722 and Opus audio codecs, 2 SIP lines, and 3-way conference advanced VoIP functionalities. By migrating to IP voice with easy-to-install ATA, the GA10 provides convenient, stable and cost-effective communication solutions for individuals, enterprises, and operators to realize the deployment of VoIP.
Key Features
- Compact FXS ATA Gateway: Single FXS port for connecting analog phones to IP networks
- HD Voice Codecs: G.722 and Opus wideband codec support for crystal-clear audio
- 2 SIP Lines: Supports 2 SIP accounts for flexible call handling
- 3-Way Conference: Built-in 3-way calling for collaborative communication
- Easy Installation: Plug-and-play setup for quick VoIP deployment
- Comprehensive Codec Support: G.711A/U, G.723, G.729A/B, iLBC, G.722, Opus
- Cost-Effective: Affordable solution for migrating analog phones to IP telephony
- Voice Features: ITU-T G.168 echo cancellation, jitter buffer, VAD, CNG, PLC
Specifications
| Model | GA10 |
| Type | SIP ATA Gateway (FXS) |
| FXS Port | 1 × RJ11 |
| SIP Lines | 2 |
| Network Port | 1 × 10/100Mbps RJ45 |
| Protocol | SIP (RFC3261) |
| Codec | G.711A, G.711U, G.723, G.729A/B, iLBC, G.722, Opus |
| Conference | 3-way |
| DTMF Mode | RFC2833, SIP Info, In-band |
| Fax | T.30, T.38 |
| Voice Capability | ITU-T G.168 Echo Cancellation, Jitter Buffer, VAD, CNG, PLC |
| QoS | √ |
| VLAN | √ |
| Provisioning | HTTP, HTTPS, FTP, TFTP |
| Power Supply | 5V 1A |
| Dimensions | 90 × 80 × 25mm |
